W24L257A
- 4 -
AC Characteristics, continued
(V
DD
= 3.3V
±
5%, V
SS
= 0V, Ta = 0 to 70
°
C)
(1) Read Cycle
PARAMETER
SYM.
W24L257A-12
W24L257A-15
W24L257A-20
UNIT
MIN.
MAX.
MIN.
MAX.
MIN.
MAX.
Read Cycle Time
T
RC
12
-
15
-
20
-
nS
Address Access Time
T
AA
-
12
-
15
-
20
nS
Chip Select Access Time
T
ACS
-
12
-
15
-
20
nS
Output Enable to Output Valid
T
AOE
-
6
-
8
-
10
nS
Chip Selection to Output in Low Z
T
CLZ
*
4
-
4
-
4
-
nS
Output Enable to Output in Low Z
T
OLZ
*
0
-
0
-
0
-
nS
Chip Deselection to Output in High Z
T
CHZ
*
-
6
-
7
-
10
nS
Output Disable to Output in High Z
T
OHZ
*
-
6
-
7
-
10
nS
Output Hold from Address Change
T
OH
3
-
3
-
3
-
nS
These parameters are sampled but not 100% tested
(2) Write Cycle
PARAMETER
SYM.
W24L257A-12
W24L257A-15
W24L257A-20
UNIT
MIN.
MAX.
MIN.
MAX.
MIN.
MAX.
Write Cycle Time
T
WC
12
-
15
-
20
-
nS
Chip Selection to End of Write
T
CW
10
-
13
-
17
-
nS
Address Valid to End of Write
T
AW
10
-
13
-
17
-
nS
Address Setup Time
T
AS
0
-
0
-
0
-
nS
Write Pulse Width
T
WP
10
-
10
-
12
-
nS
Write Recovery Time
CS
,
WE
T
WR
1
-
1
-
1
-
nS
Data Valid to End of Write
T
DW
7
-
9
-
10
-
nS
Data Hold from End of Write
T
DH
0
-
0
-
0
-
nS
Write to Output in High Z
T
WHZ
*
-
7
-
8
-
10
nS
Output Disable to Output in High Z
T
OHZ
*
-
7
-
8
-
10
nS
Output Active from End of Write
T
OW
0
-
0
-
0
-
nS
These parameters are sampled but not 100% tested
