W78L51
8-BIT MICROCONTROLLER
Publication Release Date: January 1999
- 1 -
Revision A2
GENERAL DESCRIPTION
The W78L51 microcontroller supplies a wider frequency and supply voltage range than most 8-bit
microcontrollers on the market. It is compatible with the industry standard 80C51 microcontroller
series.
The W78L51 contains four 8-bit bidirectional parallel ports, one extra 4-bit bit-addressable I/O port
(Port 4) and two additional external interrupts (
INT2
, INT3 ), two 16-bit timer/counters, one watchdog
timer and a serial port. These peripherals are supported by a seven-source, two-level interrupt
capability. There are 128 bytes of RAM and an 4K byte mask ROM for application programs.
The W78L51 microcontroller has two power reduction modes, idle mode and power-down mode, both
of which are software selectable. The idle mode turns off the processor clock but allows for continued
peripheral operation. The power-down mode stops the crystal oscillator for minimum power
consumption. The external clock can be stopped at any time and in any state without affecting the
processor.
FEATURES
Fully static design
Supply voltage of 1.8V to 5.5V
DC-24 MHz operation
128 bytes of on-chip scratchpad RAM
4K bytes of on-chip mask ROM
64K bytes program memory address space
64K bytes data memory address space
Four 8-bit bidirectional ports
Two 16-bit timer/counters
One full duplex serial port
Seven
-source, two-level interrupt capability
One extra 4-bit bit-addressable I/O port
Two additional external interrupts
INT2
/ INT3
Watchdog timer
EMI reduction mode
Built-in power management
Code protection
Packages:
DIP 40: W78L51-24
PLCC 44: W78L51P-24
QFP 44: W78L51F-24
