W78C32B
8-BIT MICROCONTROLLER
Publication Release Date: October 1997
- 1 -
Revision A3
GENERAL DESCRIPTION
The W78C32B microcontroller supplies a wider frequency range than most 8-bit microcontrollers on
the market. It is compatible with the industry standard 80C32 microcontroller series.
The W78C32B contains four 8-bit bidirectional parallel ports, three 16-bit timer/counters, and a serial
port. These peripherals are supported by a six-source, two-level interrupt capability. There are 256
bytes of RAM, and the device supports ROMless operation for application programs.
The W78C32B microcontroller has two power reduction modes, idle mode and power-down mode,
both of which are software selectable. The idle mode turns off the processor clock but allows for
continued peripheral operation. The power-down mode stops the crystal oscillator for minimum power
consumption. The external clock can be stopped at any time and in any state without affecting the
processor.
FEATURES
8-bit CMOS microcontroller
Fully static design
Low standby current at full supply voltage
DC-40 MHz operation
256 bytes of on-chip scratchpad RAM
ROMless operation
64K bytes program memory address space
64K bytes data memory address space
Four 8-bit bidirectional ports
Three 16-bit timer/counters
One full duplex serial port
Boolean processor
Six-source, two-level interrupt capability
Built-in power management
Packages:
DIP 40:
W78C32B-16/24/40
PLCC 44: W78C32BP-16/24/40
QFP 44: W78C32BF-16/24/40
TQFP 44: W78C32BM-16/24/40
