參數資料
| 型號： | W83193R-01 |
| 廠商： | WINBOND ELECTRONICS CORP |
| 元件分類： | XO, clock |
| 英文描述： | 83.MHZ 3-DIMM CLOCK |
| 中文描述： | 85.8 MHz, PROC SPECIFIC CLOCK GENERATOR, PDSO48 |
| 封裝： | SSOP-48 |
| 文件頁數： | 1/19頁 |
| 文件大小： | 237K |
| 代理商： | W83193R-01 |
W83193R-01
83.MHZ 3-DIMM CLOCK
Publication Release Date: May 1998
Revision 0.20
- 1 -
1.0 GENERAL DESCRIPTION
The W83193R-01 is a Clock Synthesizer which provides all clocks required for high-speed RISC or
CISC microprocessor such as Intel PentiumPro , AMD or Cyrix. Eight different frequency of CPU and
PCI clocks are externally selectable with smooth transitions.
The W83193R-02/-04 also provides I
2
C serial bus interface to program the registers to enable or
disable each clock outputs and choose the 0.6% or 1.5% center type spread spectrum.
The W83193R-01 accepts a 14.318 MHz reference crystal as its input and runs on a 3.3V supply.
High drive PCI and SDRAM CLOCK outputs typically provide greater than 1 V /ns slew rate into 30
pF loads. CPU CLOCK outputs typically provide better than 1 V /ns slew rate into 20 pF loads as
maintaining 50
ó
5% duty cycle. The fixed frequency outputs as REF, 24MHz, and 48 MHz provide
better than 0.5V /ns slew rate.
2.0 PRODUCT FEATURES
Supports Pentium
, Pentium
Pro, Pentium
II, AMD and Cyrix CPUs with I
2
C.
4 CPU clocks.
12 SDRAM clocks for 3 DIMs.
7 PCI synchronous clocks.
One IOAPIC clock for multiprocessor support.
Optional single or mixed supply:
(Vdd = Vddq3 = Vddq2 = 3.3V) or (Vdd = Vddq3 = 3.3V, Vddq2 = 2.5V)
< 250ps skew among CPU and SDRAM clocks.
< 250ps skew among PCI clocks.
Smooth frequency switch with selections from 50 MHz to 83.3 MHz CPU.
I
2
C 2-Wire serial interface.
0.6% or 1.5% center type spread spectrum function to reduce EMI.
Programmable registers to enable/stop each output and select modes.
(mode as Tri-state, or Normal )
MODE pin for power Management.
48 MHz for USB.
24 MHz for super I/O.
48-pin SSOP package.
