WFP6540B
October 5, 1999
Rev. 0.01
1999 Winbond Electronics Corporation
1
Advanced Product Information
COG Signal Driver
258-Channel, 6-Bit Signal Driver for
XGA COG Applications
1.
PRODUCT DESCRIPTION
The WFP6540B s a 6-bit, 258-channel signal
driver designed for 11.x and 12.x XGA chip-on-
glass (COG) TFT-LCDs. The WFP6540B’s mini-
mum form factor and optimized COG layout per-
mit the design of high-display-quality, low-power
6-bit TFT-LCD’s with minimum bezel area.
The WFP6540B’s internal architecture includes a
resistor-string DAC with the value of the individual
resistor segments weighted to reduce signal
driver power dissipation by as much as 20% to
40% when compared to non-weighted resistor
string DAC architectures.
258
Gate
Driver
258
258
1024 x 768
262,144-Color LCD
Gate
Driver
Data
...
.
Reference
Amplifier
Circuit
LCD
Control
ASIC
WFP6540B
Signal Driver
WFP6540B
Signal Driver
WFP6540B
Signal Driver
from
Graphics
Controller
Control
