Distributor: Electro-Stock www.electrostock.com Tel: 630-682-1542 Fax: 630-682-1562
FEATURES:
Low profile
Small size and light weight
Coil voltages up to 100VDC
UL/CUL certified
E197852
22.2 x 16.5 x 10.9 mm
CONTACT DATA
Contact Arrangement
1A = SPST N.O.
1C = SPDT
1A: 16A @ 250VAC
1C: 10A @ 250VAC
< 50 milliohms initial
AgCdO
300W
380VAC, 110VDC
16A
Contact Rating
Contact Resistance
Contact Material
Maximum Switching Power
Maximum Switching Voltage
Maximum Switching Current
COIL DATA
Coil Voltage
VDC
Coil
Resistance
±
10%
.20W
125
180
405
720
1620
2880
9216
16600
Rated
5
6
9
12
18
24
48
100
CAUTION:
1. The use of any coil voltage less than the rated coil voltage may compromise the operation of the relay.
2. Pickup and release voltages are for test purposes only and are not to be used as design criteria.
GENERAL DATA
Electrical Life @ rated load
Mechanical Life
10M cycles, typical
Insulation Resistance
100M
min @ 500VDC
Dielectric Strength, Coil to Contact
Contact to Contact
750V rms min. @ sea level
Shock Resistance
100m/s
2
for 11ms
Vibration Resistance
1.50mm double amplitude 10-40Hz
Terminal (Copper Alloy) Strength
10N
Operating Temperature
Storage Temperature
-40
°
C to + 155
°
C
Solderability
230
°
C
±
2
°
C for 10
±
0.5s
Weight
10g
Max.
6.5
7.8
11.7
15.6
23.4
31.2
62.4
130.0
.45W
56
80
180
320
720
1280
5120
Pick Up Voltage
VDC (max)
75%
of rated voltage
Release Voltage
VDC (min)
10%
of rated voltage
Coil Power
W
Operate Time
ms
Release Time
ms
3.75
4.50
6.75
9.00
13.5
18.00
36.00
75.0
0.5
0.6
0.9
1.2
1.8
2.4
4.8
10.0
.20
.45
.25 or .45
.60
8
5
100K cycles, typical
1500V rms min. @ sea level
-40
°
C to + 85
°
C
WJ111
