ZR36750
Product Brief
Tel 408.919.4111
Fax 408.919.4122
www.zoran.com
10/02-LDI
Benefits Overview
The Vaddis 5 (ZR36750) is a DVD Multimedia Processor combining
advanced DVD playback capability with Web browsing and flexible
video mixing capabilities for creating leading-edge consumer
audio/video products. With its integrated 135 MHz MIPS RISC CPU,
135 MHz DSP, MPEG-2 video decoder and graphics processor, it
delivers high quality to fully integrated displays.
The unified memory architecture allows flexibility for future product
designs. Through the StandardsPlus design methodology, Zoran
builds upon the industry standards to provide leading-edge
capabilities for advanced DVD players and audio/video appliances.
The Vaddis 5 accesses Zoran’s extensive SiliconSoftware library,
with a variety of innovative audio algorithms. The Vaddis 5 is the
ideal IC solution for DVD, iDVD, Personal Video Recorder (PVR),
DVD Recording and Video-On-Demand products.
Features
Single-chip solution for DVD-Video, DVD-Audio, and Web
browsing
Full standard support: DVD-Video, DVD-Audio, SVCD, VCD
Integrated 135 MHz 32-bit RISC Processor
High Performance 135 MHz 32-bit DSP
Motion-adaptive Pixel-by
-
Pixel deinterlacing for progressive
scan video output
Film detection (3:2 and 2:2) and bad edit detection
On-chip graphics engine with three display planes
Unified memory architecture
32-bit On Screen Display (OSD)
Antiflicker video filtering for high quality Web display
Digital video input and output ports
Embedded NTSC/PAL/480P encoder with six 10-bit video DACs
Picture-in-Picture for DVD, Web, and external video source
Image enhancement filtering: sharpening, brightness and equalization
MLP decoding, linear PCM and watermarking for DVD-
Audio applications
10 audio outputs, 2 audio input channels for flexibility
DTS, Dolby Digital, Pro Logic, MPEG 5.1 audio decoding, virtual
surround sound and 3D headphones
Advanced trick play features, including smooth scan,
ZoranZoom, and smooth reverse playback
ATAPI, A/V, UDE, and S2B drive support
SmartMedia and SD FLASH glueless memory interfaces
RTOS, Software Development Tools, API
Vaddis 5 API and Software Development Tool Kit
316-pin BGA package
0.18 micron technology
Zoran Corporation
3112 Scott Boulevard
Santa Clara, CA 95054-3317
ZR36750-PB-4.0
Applications
Web-ready iDVD players
DVD-Video/DVD-Audio/SVCD/VCD/CVD/HDCD/CD players
DVD recorders
Personal Video Recorders (PVR)
Automotive DVD/DVD-Audio entertainment systems
Portable DVD players
Feature Description
DVD Processing
The Vaddis 5 is the ideal solution for universal DVD players, fully
supporting both DVD-Video and DVD-Audio playback. This single-
chip solution performs DVD demultiplexing and parsing, MPEG-2 or
MPEG-1 video decoding, subpicture decoding, highlight processing,
and audio/video synchronization. Content Protection for Prerecorded
Media (CPPM) and Content Protection for Recordable Media
(CPRM) support is integrated. The on-chip graphics processor and
OSD units provide great flexibility in creating sophisticated on-
screen user interfaces.
Web Browsing
The Vaddis 5 system-on-a-chip architecture enables simultaneous
DVD playback and high-quality Web browsing with its powerful CPU
and hardware accelerators. The on-chip 2D graphics engine with
three display planes enables full-screen display of 16-bit color user
interfaces and content. DSP acceleration for decoding of
compressed still images and Internet audio allow for an enriching
user experience. Separate OSD planes allow for efficient partitioning
of user interfaces and content for maximum throughput. Hardware
deflicker filtering enables the high quality display of Web content
on an interlaced television display. The combination of an embedded
CPU, graphics processing and video filtering enable true iDVD
applications.
VADDIS
5
DVD MULTIMEDIA PROCESSOR
Solutions on a chip for enjoying the digital life style
