| 型號： | 0050348577 |
| 廠商： | MOLEX INC |
| 元件分類： | 電源輸入模塊 |
| 英文描述： | 3 CONTACT(S), MALE, POWER CONNECTOR, SOLDER |
| 封裝： | ROHS COMPLIANT |
| 文件頁數： | 2/2頁 |
| 文件大小： | 34K |
| 代理商： | 0050348577 |
Surface Mount Compatible (SMC)
No
Temperature Range - Operating
-40°C to +105°C
Termination Interface: Style
Through Hole
Electrical
CSA
LR19980
Current - Maximum
12A
Current - Maximum
9A
TUV
R72081037
UL
E29179
Voltage - Maximum
600V
Solder Process Data
Duration at Max. Process Temperature (seconds)
5
Lead-free Process Capability
Wave Capable (TH only)
Max. Cycles at Max. Process Temperature
1
Process Temperature max. C
240
Material Info
Old Part Number
5569-03A4MS-210
Reference - Drawing Numbers
Product Specification
PS-5556-001
Sales Drawing
SDA-5569-03A**
This document was generated on 11/06/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
