參數資料
| 型號： | 0430252200 |
| 廠商： | MOLEX INC |
| 元件分類： | 電路板相疊連接器 |
| 英文描述： | 22 CONTACT(S), FEMALE, STRAIGHT TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE |
| 封裝： | ROHS COMPLIANT |
| 文件頁數： | 3/4頁 |
| 文件大?。?/td> | 151K |
| 代理商： | 0430252200 |
Physical
Circuits (maximum)
22
Circuits Detail
22
Color - Resin
Black
Flammability
94V-0
Gender
Female
Glow-Wire Compliant
No
Keying to Mating Part
None
Lock to Mating Part
Yes
Material - Resin
Polyester
Number of Rows
2
Packaging Type
Bag
Panel Mount
No
Pitch - Mating Interface (in)
0.118 In
Pitch - Mating Interface (mm)
3.00 mm
Polarized to Mating Part
Yes
Stackable
No
Temperature Range - Operating -40°C to +105°C
Electrical(Please review the Product Specification for specific details.)
Current - Maximum per Contact
5A
Agency Certification
CSA
LR19980
TUV
R72081037
UL
E29179
Material Info
Reference - Drawing Numbers
Product Specification
PS-43045, RPS-43045-003, RPS-43045-004
Sales Drawing
SDA-43025-****
Copyright 2005-2010
Feedback
Privacy
Legal
Site Map
Help
Find us on:
Molex Connector Part Number - 0430252200
Page 3 of 4
C:\TEMP\04192010\MOLE\0430252200.mht
20-Apr-2010
