Dimensions are shown in mm (inch)

Dimensions subject to change

119

Assy Insts

RF Coaxial Connectors

Assembly Instructions

AI-436, AI-499 & AI-523

SMS & SSIS Straight and Right Angle Connectors, Direct Solder Type for Semi-Rigid Cable

1. Trim cable to dimensions shown, being careful not to nick center conductor

‘A’ = 2,29 (.090).

2. Insert cable into rear of body until cable seats in counterbore. Holding firm in this position. Solder

cable to body.

NOTE

Only common cable entry features are shown in detail. Various body configurations can apply.

BODY ASSEMBLY
