| 型號： | 203195 |
| 廠商： | ERNI ELECTRONICS INC |
| 元件分類： | 電信和以太網連接器 |
| 英文描述： | 32 CONTACT(S), FEMALE, TELECOM AND DATACOM CONNECTOR, SOLDER, JACK |
| 文件頁數： | 1/2頁 |
| 文件大小： | 46K |
| 代理商： | 203195 |
Date
Change No.
Name
Plot At
Group/Type
203195
8C8T, 2X2, INTEGRATED MAGNETICS
MOD JACK - MJIM
MAXMJ
2:1
a
18FEB04
-
I
NOTE 1: PANEL GROUND FLANGES TOP, BOTTOM, SIDES (GF9)
NOTE 2: ONE GROUNDING PIN CENTERED
HOUSING: GLASS FILLED POLYESTER UL 94 V-0 BLACK
DURABILITY: 1000 MATING CYCLES
CONTACTS: PHOSPHOR BRONZE
MECHANICAL CHARACTERISTICS
CONTACT FINISH: Au, 0.8
m (30 in) OVER Ni
OPERATING TEMPERATURE: 0C TO 70C
CONTACT RESISTANCE: 30 MILLIOHMS MAX
ELECTRICAL CHARACTERISTICS
INNER SHIELDING: Cu ALLOY, PLATED WITH Sn
TERMINAL FINISH: SnPb
MATERIALS AND FINISH
OUTER SHIELDING: STAINLESS STEEL
RECOMMENDED PANEL CUTOUT
EMPFOHLENER FRONTPLATTEN AUSSCHNITT
TOP OF PCB
LP
1
8
1
8
1
28.50 [1.122] MAX
25.50
[1.004]
MAX
3.50
±0.30
[.138
±.012]
32.34 [1.273]
0.38
±0.10
[.015
±.004]
26.16
[1.030]
31.24 [1.230]
13.97 [.550]
25.40
±0.13 [1.000±.005]
10.89 [.429]
Scale
Designation
Tolerances
Consider
pr
otection
memo
fr
om
DIN
34
All rights reserved.
Only for information.
To insure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
Subject to modification without
prior notice.
Drawing will not be updated.
Index
Information:
NOTE 3: 3 SIDE GROUND TABS EACH SIDE; STAGGERED (S1)
SCHEMATIC NUMBER: M3D01
All Dimensions
in mm
www.ERNI.com
