The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
JUNCTION FIELD EFFECT TRANSISTOR
2SK2552B
N-CHANNEL SILICON JUNCTION FIELD EFFECT TRANSISTOR
FOR IMPEDANCE CONVERTER OF ECM
DATA SHEET
Document No. D17282EJ1V0DS00 (1st edition)
Date Published August 2004 NS CP(K)
Printed in Japan
2004
DESCRIPTION
The 2SK2552B is suitable for converter of ECM.
General-purpose product.
FEATURES
Low noise:
108.5 dB TYP. (V
DD
= 2.0 V, C = 5 pF, R
L
= 2.2 k
)
Especially suitable for audio and telephone
Small package:
SC-75 (USM)
ORDERING INFORMATION
PART NUMBER
PACKAGE
2SK2552B
SC-75 (USM)
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C)
Drain to Source Voltage (V
GS
=
1.0 V)
V
DSX
20
V
Gate to Drain Voltage
V
GDO
20
V
Drain Current
I
D
10
mA
Gate Current
I
G
10
mA
Total Power Dissipation
P
T
100
mW
Junction Temperature
T
j
125
°C
Storage Temperature
T
stg
55 to +125
°C
Caution Please take care of ESD (Electro Static Discharge) when you handle the device in this document.
PACKAGE DRAWING (Unit: mm)
0.3
+0.1
–0
0.6
TYP.
0 to 0.1
1
0
0.5
TYP.
1.0 TYP.
1.6 ±0.1
0.5
TYP.
0.75 ±0.05
0.15
+0.1
0.2
+0.1
–0
1
2
3
EQUIVALENT CIRCUIT
3
2
1
1: Source
2: Drain
3: Gate
