Electronic Components | Segments | Who We Are
Searc h
624-AG1T Product Details
No Im age Available
624-AG1T
(5-1437515-6)
T E I nternal N umber: 5 -1 4 3 7 5 1 5 -6
Plug Adapter Assemblies
Product Highlights:
l
Assembly (Insulator and Pins)
l
24 Pins
l
Pin Style = Round
l
Tin Pin Plating
l
Row-to-Row Spacing = 15.24 mm
Quick Links
Documentation & Additional Information
Product Drawings:
l
Adapters (PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Assembly (Insulator and Pins)
l
Product Series = 600 Series
Electrical Characteristics:
l
Insulator Flammability Rating = UL94V-0
Termination Related Features:
l
Number of Pins = 24
Body Related Features:
l
Pin Style = Round
l
Pin Plating = Tin
l
Row-to-Row Spacing (mm [in]) = 15.24 [0.600]
l
Pin Material = Phosphor Bronze
l
Insulator Material = Thermoplastic Polyester
Industry Standards:
l
RoHS/ELV Compliance = Not ELV/RoHS compliant
l
Lead Free Solder Processes = Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
Conditions for Usage:
l
Operating Temperature (?C ) = -65 – +125
Other:
l
Brand = AMP
