MAX4675/MAX4676
3
Single SPST Analog Switches
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS—DUAL SUPPLIES
(V+ = +5V ±10%, V- = -5V ±10%, GND = 0, VIH = +2.4V, VIL = 0.8V, TA = TMIN to TMAX, unless otherwise noted. Typical values are
at TA = +25°C.) (Notes 2, 3)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V+ to GND ................................................................-0.3V to +6V
V- to GND .................................................................+0.3V to -6V
V+ to V- ..................................................................................12V
IN to GND .....................................................-0.3V to (V+ + 0.3V)
All Other Pins (Note 1) ..........................(V- - 0.3V) to (V+ + 0.3V)
Continuous Current (NO, NC, COM) ..............................±100mA
Peak Current (NO, NC, COM, pulsed at 1ms
(10% duty cycle).........................................................±200mA
Continuous Power Dissipation (TA = +70°C)
6-Pin SOT23 (derate 8.7mW/°C above +70°C)............691mW
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
Note 1: Signals on NO, NC, COM, or IN exceeding V+ or V- will be clamped by internal diodes. Limit forward diode current to maxi-
mum current rating.
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
ANALOG SWITCH
Input Voltage Range
VCOM,
VNO, VNC
V-
V+
V
TA = +25
°C
2.4
3
On-Resistance
RON
V+ = 4.5V, V- = -4.5V, ICOM
= 50mA; VNO or VNC =
±3.3V
TA = TMIN to TMAX
4
TA = +25
°C
0.4
0.7
On-Resistance Flatness
(Note 4)
RFLAT
V+ = 4.5V, V- = -4.5V,
ICOM = 50mA; VNO or
VNC =
±3.3V, 0
TA = TMIN to TMAX
1.0
TA = +25
°C
-1
0.1
1
NC or NO Off-Leakage
Current
IN_(OFF)
V+ = 5.5V, V- = -5.5V,
VCOM = 4.5V; VNO or VNC =
±4.5V
TA = TMIN to TMAX
-10
10
nA
TA = +25
°C
-1
0.1
1
COM Off-Leakage Current
ICOM(OFF)
V+ = 5.5V, V- = -5.5V,
VCOM = +4.5V; VNO or
VNC =
±4.5V
TA = TMIN to TMAX
-10
10
nA
TA = +25
°C
-2
0.1
2
COM On-Leakage Current
ICOM(ON)
V+ = 5.5V, V- = -5.5V,
VCOM =
±4.5V; VNO or VNC
=
± 4.5V or floating
TA = TMIN to TMAX
-20
20
nA
LOGIC INPUT
Input Low Voltage
VIL
0.8
V
Input High Voltage
VIH
2.4
V
Input Leakage Current
IIN
-1
0.005
1
A
DYNAMIC
TA = +25
°C
135
300
Turn-On Time
tON
V+ = +4.5V, V- = -4.5V;
VNO or VNC = 3.3V,
RL= 300
, CL= 35pF, Figure 2
TA = TMIN to TMAX
375
ns
TA = +25
°C
50
110
Turn-Off Time
tOFF
V+ = +4.5V, V- = -4.5V;
VNO or VNC = 3.3V,
RL= 300
, CL= 35pF, Figure 2
TA = TMIN to TMAX
125
ns
