參數資料
| 型號： | 5962-90538012A |
| 元件分類： | 整流器 |
| 英文描述： | SILICON, RECTIFIER DIODE |
| 封裝： | CERAMIC, LCC-20 |
| 文件頁數： | 5/6頁 |
| 文件大小： | 210K |
| 代理商： | 5962-90538012A |
1 of 2
Search Power Portal
Power Management Home
> > Power Management > Power Supply Support > Schottky Diode Arrays
UC1611, QUAD SCHOTTKY DIODE ARRAY
Device Status: Active
Description
Features
> Description
> Features
> Datasheets
> Pricing/Samples/Availability
> Application Notes
Parameter Name UC1611
Output Current (A) 1
Vin (V)
0
Vin (max) (V)
50
Pin Count
8
This four-diode array is designed for general purpose use as individual diodes or as a high-
speed, high-current bridge. It is particularly useful on the outputs of high-speed power
MOSFET drivers where Schottky diodes are needed to clamp any negative excursions
caused by ringing on the driven line.
These diodes are also ideally suited for use as voltage clamps when driving inductive loads
such as relays and solenoids, and to provide a path for current free-wheeling in motor drive
applications.
The use of Schottky diode technology features high efficiency through lowered forward
voltage drop and decreased reverse recovery time.
This single monolithic chip is fabricated in both hermetic CERDIP and copper-leaded
plastic packages. The UC1611 in ceramic is designed for -55°C to +125°C environments but
with reduced peak current capability: while the UC3611 in plastic has higher current rating
over a 0°C to +70°C ambient temperature range.
l
Matched, Four-Diode Monolithic Array
