Absolute Maximum Ratings (Note 9)
If Military/Aerospace specified devices are required, please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
LM158/LM258/LM358
LM2904
LM158A/LM258A/LM358A
Supply Voltage, V
+
32V
26V
Differential Input Voltage
32V
26V
Input Voltage
0.3V to +32V
0.3V to +26V
Power Dissipation (Note 1)
Molded DIP
830 mW
Metal Can
550 mW
Small Outline Package (M)
530 mW
micro SMD
435mW
Output Short-Circuit to GND
(One Amplifier) (Note 2)
V
+
≤ 15V and T
A = 25C
Continuous
Input Current (V
IN < 0.3V) (Note 3)
50 mA
Operating Temperature Range
LM358
0C to +70C
40C to +85C
LM258
25C to +85C
LM158
55C to +125C
Storage Temperature Range
65C to +150C
Lead Temperature, DIP
(Soldering, 10 seconds)
260C
Lead Temperature, Metal Can
(Soldering, 10 seconds)
300C
Soldering Information
Dual-In-Line Package
Soldering (10 seconds)
260C
Small Outline Package
Vapor Phase (60 seconds)
215C
Infrared (15 seconds)
220C
See AN-450 “Surface Mounting Methods and Their Effect on Product Reliability” for other methods of soldering
surface mount devices.
ESD Tolerance (Note 10)
250V
Electrical Characteristics
V
+ = +5.0V, unless otherwise stated
Parameter
Conditions
LM158A
LM358A
LM158/LM258
Units
Min Typ
Max
Min Typ
Max
Min Typ
Max
Input Offset Voltage
(Note 5), T
A = 25C
1
2
3
2
5
mV
Input Bias Current
I
IN(+) or IIN(),TA = 25C,
20
50
45
100
45
150
nA
V
CM = 0V, (Note 6)
Input Offset Current
I
IN(+) IIN(),VCM = 0V, TA = 25C
2
10
5
30
3
30
nA
Input Common-Mode
V
+ = 30V, (Note 7)
0
V
+1.5
0
V
+1.5
0
V
+1.5
V
Voltage Range
(LM2904, V
+ = 26V), T
A = 25C
Supply Current
Over Full Temperature Range
R
L = ∞ on All Op Amps
V
+ = 30V (LM2904 V+ = 26V)
1
2
1
2
1
2
mA
V
+ = 5V
0.5
1.2
0.5
1.2
0.5
1.2
mA
LM158/LM258/LM358/LM2904
www.national.com
2
