Absolute Maximum Ratings (Note 13)
If Military/Aerospace specified devices are required, please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
LM139/LM239/LM339
LM139A/LM239A/LM339A
LM3302
LM2901
Supply Voltage, V
+
36 V
DC or ±18 VDC
28 V
DC or ±14 VDC
Differential Input Voltage (Note 11)
36 V
DC
28 V
DC
Input Voltage
0.3 V
DC to +36 VDC
0.3 V
DC to +28 VDC
Input Current (V
IN<0.3 VDC),
(Note 6)
50 mA
Power Dissipation (Note 4)
Molded DIP
1050 mW
Cavity DIP
1190 mW
Small Outline Package
760 mW
Output Short-Circuit to GND,
(Note 5)
Continuous
Storage Temperature Range
65C to +150C
Lead Temperature
(Soldering, 10 seconds)
260C
Operating Temperature Range
40C to +85C
LM339/LM339A
0C to +70C
LM239/LM239A
25C to +85C
LM2901
40C to +85C
LM139/LM139A
55C to +125C
Soldering Information
Dual-In-Line Package
Soldering (10 seconds)
260C
Small Outline Package
Vapor Phase (60 seconds)
215C
Infrared (15 seconds)
220C
See AN-450 “Surface Mounting Methods and Their Effect on Product Reliability” for other methods of soldering surface mount
devices.
ESD rating (1.5 k
in series with 100 pF)
600V
Electrical Characteristics
(V
+=5V
DC,TA = 25C, unless otherwise stated)
Parameter
Conditions
LM139A
LM239A, LM339A
LM139
Units
Min Typ
Max
Min
Typ
Max
Min Typ
Max
Input Offset Voltage
(Note 12)
1.0
2.0
1.0
2.0
5.0
mV
DC
Input Bias Current
I
IN(+) or IIN() with Output in
25
100
25
250
25
100
nA
DC
Linear Range, (Note 8), V
CM=0V
Input Offset Current
I
IN(+)IIN(),VCM=0V
3.0
25
5.0
50
3.0
25
nA
DC
Input Common-Mode
V
+=30 V
DC (LM3302,
0
V
+1.5
0
V
+1.5
0
V
+1.5
V
DC
Voltage Range
V
+=28 V
DC) (Note 9)
Supply Current
R
L= ∞ on all Comparators,
0.8
2.0
0.8
2.0
0.8
2.0
mA
DC
R
L= ∞,V
+=36V,
1.0
2.5
1.0
2.5
mA
DC
(LM3302, V
+=28 V
DC)
Voltage Gain
R
L≥15 k,V
+=15 V
DC
50 200
50
200
50 200
V/mV
V
o= 1VDC to 11 VDC
Large Signal
V
IN=TTL Logic Swing, VREF=
300
ns
Response Time
1.4 V
DC,VRL=5VDC,
R
L=5.1 k
Response Time
V
RL=5VDC,RL=5.1 k,
1.3
s
(Note 10)
www.national.com
3
