Struthers-Dunn
407 East Smith Street - Suite B
Timmonsville, SC 29161 US
Phone:
(843) 346-4427
Fax:
(843) 346-4465
E-Mail:
Web site:www.struthers-dunn.com
Item # 645TR410-3-32VDC, 645T Series - Solid State On / Off Motor Relays
645T Series - Solid State On / Off Motor Relays
The 645T series of solid state relays uses triacs for on/off control of three phase loads. Operation is three pole normally open. Inputs can be AC or DC operated. Load
currents can range from 10 to 50 amps and up to a nominal voltage of 480VAC. Both random turn on or zero cross is available.
For Additional Configuration please contact the manufacturer.
·
SPECIFICATIONS
·
INPUT CHARACTERISTICS
·
OUTPUT CHARACTERISTICS
·
MISCELLANEOUS
CHARACTERISTICS
SPECIFICATIONS
Series
645T
INPUT CHARACTERISTICS
Input Voltage
3-32 VDC
Input Characteristics
DC
Must Release Voltage
1VDC
Maximum Input Current
80 mA
Reverse Polarity Protection
Yes
OUTPUT CHARACTERISTICS
Output Characteristics
10 A
Min. Load current to maintain on
100 mA
3/1/2011 | Page 1 of 2
