Philips Semiconductors - PIP - HEF4067B MSI; 16-channel analogue multiplexer/demultiplexer
Product Information
HEF4067B MSI; 16-
channel analogue
multiplexer/demultiplexer
Information as of 2003-04-22
Stay informed
Download datasheet
Features
Applications
Block diagram
topGeneral description
The HEF4067B is a 16-channel analogue multiplexer/demultiplexer with four address inputs (A0 to A3 ), an active LOW
enable input (E), sixteen independent inputs/outputs (Y0 to Y15 ) and a common input/output (Z). The device contains
sixteen bidirectional analogue switches, each with one side connected to an independent input/output (Y0 to Y15 ) and the
other side connected to the common input/output (Z).
With E LOW, one of the sixteen switches is selected (low impedance ON-state) by A0 to A3 . All unselected switches are
in the high impedance OFF-state. With E HIGH all switches are in the high impedance OFF-state, independent of A0 to
A3 .
The analogue inputs/outputs (Y0 to Y15 and Z) can swing between VDD as a positive limit and VSS as a negative limit.
VDD to VSS may not exceed 15 V.
topDatasheet
Datasheet status Page
count
File
size
(kB)
Datasheet
HEF4067B
MSI
16-channel analogue
multiplexer/demultiplexer
1/1/1995
Product
specification
9
106
Additional datasheet info
To complete the device datasheet with package and family information, also download the following PDF files .
Document
Description
1 Download
HEF_FAMILY_SPECIFICATIONS HEF Family Specifications, The IC04 LOCMOS HE4000B Logic Family
Specifications HEF, HEC
2 Download
HEF Package Outlines/Info, The IC04 LOCMOS HE4000B Logic
Package Outlines/Information HEF, HEC
