| 型號： | 933650380602 |
| 廠商： | NXP SEMICONDUCTORS |
| 元件分類： | DAC |
| 英文描述： | PARALLEL, 8 BITS INPUT LOADING, 0.07 us SETTLING TIME, 8-BIT DAC, PDSO16 |
| 封裝： | PLASTIC, SOT-109, SO-16 |
| 文件頁數： | 6/15頁 |
| 文件大?。?/td> | 266K |
| 代理商： | 933650380602 |
l
Relative accuracy to 0.1% maximum over temperature range
l
High output compliance -10V to +18V
l
True and complemented outputs
l
Wide range multiplying capability
l
Low f
s current drift- ±10ppm/°C
l
Wide power supply range- ± 4.5V to ±18V
l
Low power consumption-37mW at ±5V
l
8-bit, 1ms A-to-D converters
l
Servo-motor and pen drivers
l
Waveform generators
l
Audio encoders and attenuators
l
Analog meter drivers
l
Programmable power supplies
l
CRT display drivers
l
High-speed modems
l
Other applications where low cost, high speed and complete in-put/ output versatility are required
l
Programmable gain and attenuation
l
Analog-Digital multiplication
Applications
Datasheet
Type nr.
Title
Publication
release date
Datasheet status
Page
count
File
size
(kB)
Datasheet
DAC08 Series 8-Bit high-speed multiplying D/A
converter
31-Aug-94
Product
Specification
12
227
Download
Products, packages, availability and ordering
Partnumber
North American
Partnumber
Order code
(12nc)
marking/packing
package device status
buy online
DAC-
08CN
DAC-08CN
9336 720 70602 Standard Marking * Tube (Signetics)
SOT38
Full production
DAC-08ED DAC-08ED
9336 503 80602 Standard Marking * Tube (Signetics)
SOT109 Full production
DAC-08ED-T
9336 503 80623
Standard Marking * Reel Pack, SMD,
13" (Signetics)
SOT109 Full production
DAC-08EN DAC-08EN
9336 645 60602 Standard Marking * Tube (Signetics)
SOT38
Full production
