DAC08 Series
Information as of 2000-08-21
DAC08 Series; 8-Bit high-speed multiplying D/A converter
The DAC08 series of 8-bit monolithic multiplying Digital-to-Analog Converters provide very high-speed performance coupled with low cost
and outstanding applications flexibility.
Advanced circuit design achieves 70ns settling times with very low glitch and at low power consumption. Monotonic multiplying
performance is attained over a wide 20-to-1 reference current range.
Matching to within 1 LSB between reference and full-scale currents eliminates the need for full-scale trimming in most applications.
Direct interface to all popular logic families with full noise immunity is provided by the high swing, adjustable threshold logic inputs.
Dual complementary outputs are provided, increasing versatility and enabling differential operation to effectively double the peak-to-peak
output swing. True high Voltage compliance outputs allow direct output V
OLtage conversion and eliminate output op amps in many
applications.
All DAC08 series models guarantee full 8-bit monotonicity and linearities as tight as 0.1% over the entire operating temperature range.
Device performance is essentially unchanged over the ±4.5V to ±18V power supply range, with 37mW power consumption attainable at
±5V supplies.
The compact size and low power consumption make the DAC08 attractive for portable and military aerospace applications.
l
Fast settling output current-70ns
l
Full-scale current prematched to ±1 LSB
l
Direct interface to TTL, CMOS, ECL, HTL, PMOS
Description
Features
Applications
Datasheet
Products, packages, availability and ordering
Find similar products
To be kept informed on DAC08 Series,
subscribe to eNews.
Subscribe
to eNews
Description
Features
