2001 Oct 22
3
Philips Semiconductors
Product specication
600 MHz, 18.2 dB gain push-pull amplier
BGY685A
CHARACTERISTICS
Table 1
Bandwidth 40 to 600 MHz; Tcase =30 °C; ZS =ZL =75
Notes
1. fp = 55.25 MHz; Vp = 44 dBmV;
fq = 541.25 MHz; Vq = 44 dBmV;
measured at fp +fq = 596.5 MHz.
2. fp = 590.25 MHz; Vp =Vo;
fq = 597.25 MHz; Vq =Vo 6 dB;
fr = 599.25 MHz; Vr =Vo 6 dB;
measured at fp +fq fr = 588.25 MHz.
3. The module normally operates at VB = 24 V, but is able to withstand supply transients up to 30 V.
SYMBOL
PARAMETER
CONDITIONS
MIN.
MAX.
UNIT
Gp
power gain
f = 50 MHz
17.7
18.7
dB
f = 600 MHz
19
dB
SL
slope cable equivalent
f = 40 to 600 MHz
0.5
2.2
dB
FL
atness of frequency response
f = 40 to 600 MHz
±0.2
dB
S11
input return losses
f = 40 to 80 MHz
20
dB
f = 80 to 160 MHz
19
dB
f = 160 to 600 MHz
18
dB
S22
output return losses
f = 40 to 80 MHz
20
dB
f = 80 to 160 MHz
19
dB
f = 160 to 600 MHz
18
dB
S21
phase response
f = 50 MHz
45
+45
deg
CTB
composite triple beat
85 channels at; Vo = 44 dBmV;
measured at 595.25 MHz
55
dB
Xmod
cross modulation
85 channels at; Vo = 44 dBmV;
measured at 55.25 MHz
60
dB
CSO
composite second order
distortion
85 channels at; Vo = 44 dBmV;
measured at 596.5 MHz
56
dB
d2
second order distortion
note 1
70
dB
Vo
output voltage
dim = 60 dB; note 2
60
dBmV
F
noise gure
f = 600 MHz
8.5
dB
Itot
total current consumption (DC)
note 3
240
mA
