2001 Oct 22
4
Philips Semiconductors
Product specication
600 MHz, 18.2 dB gain push-pull amplier
BGY685A
Table 2
Bandwidth 40 to 550 MHz; Tcase =30 °C; ZS =ZL =75
Notes
1. fp = 55.25 MHz; Vp = 44 dBmV;
fq = 493.25 MHz; Vq = 44 dBmV;
measured at fp +fq = 548.5 MHz.
2. fp = 540.25 MHz; Vp =Vo;
fq = 547.25 MHz; Vq =Vo 6 dB;
fr = 549.25 MHz; Vr =Vo 6 dB;
measured at fp +fq fr = 538.25 MHz.
3. The module normally operates at VB = 24 V, but is able to withstand supply transients up to 30 V.
SYMBOL
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
Gp
power gain
f = 50 MHz
17.7
18.7
dB
f = 550 MHz
18.8
20
dB
SL
slope cable equivalent
f = 40 to 550 MHz
0.5
2dB
FL
atness of frequency response
f = 40 to 550 MHz
±0.2
dB
S11
input return losses
f = 40 to 80 MHz
20
dB
f = 80 to 160 MHz
19
dB
f = 160 to 550 MHz
18
dB
S22
output return losses
f = 40 to 80 MHz
20
dB
f = 80 to 160 MHz
19
dB
f = 160 to 550 MHz
18
dB
S21
phase response
f = 50 MHz
45
+45
deg
CTB
composite triple beat
77 channels at; Vo = 44 dBmV;
measured at 547.25 MHz
59
dB
Xmod
cross modulation
77 channels at; Vo = 44 dBmV;
measured at 55.25 MHz
62
dB
CSO
composite second order
distortion
77 channels at; Vo = 44 dBmV;
measured at 548.5 MHz
59
dB
d2
second order distortion
note 1
72
dB
Vo
output voltage
dim = 60 dB; note 2
61.5
dBmV
F
noise gure
f = 550 MHz
8dB
Itot
total current consumption (DC)
note 3
220
240
mA
