1996 Sep 26
4
Philips Semiconductors
Product specication
Damper diode
BY228
GRAPHICAL DATA
Fig.2
Maximum total power dissipation as a
function of working peak forward current.
Solid line: basic high-voltage E/W modulator circuit; see Fig.8.
Dotted line: basic conventional horizontal deflection circuit; see Fig.9.
Curves include power dissipation due to switching losses.
handbook, halfpage
05
4
3
2
1
0
MBH407
0.75
0.25
0.50
1.25
1.00
IFWM (A)
Ptot
(W)
Fig.3
Forward current as a function of forward
voltage; maximum values.
Dotted line: Tj = 150 °C.
Solid line: Tj =25 °C.
handbook, halfpage
02
1
0
MBH408
3
1
2
5
4
VF (V)
IF
(A)
Fig.4 Device mounted on a printed-circuit board.
Dimensions in mm.
handbook, halfpage
MGA200
3
2
7
50
25
50
Fig.5
Mounting with additional printed circuit
board for heat sink purposes.
Dimensions in mm.
handbook, halfpage
35
30
10
MGA204
25.4
10
3 cm2
copper
3 cm2
copper
