1999 Aug 27
4
Philips Semiconductors
Product specication
Silicon PIN diode
BAP64-03
GRAPHICAL DATA
handbook, halfpage
102
10
1
101
MCD773
101
1
IF (mA)
rD
(
)
10
102
Fig.2
Forward resistance as a function of forward
current; typical values.
f = 100 MHz; Tj =25 °C.
handbook, halfpage
020
500
0
100
200
300
400
4
Cd
(fF)
VR (V)
812
16
MCD774
Fig.3
Diode capacitance as a function of reverse
voltage; typical values.
f = 1 MHz; Tj =25 °C.
handbook, halfpage
0.5
3
0
5
S21
2
(dB)
4
3
2
1
f (GHz)
(1)
(2)
(3)
(4)
1.5
2
2.5
MCD775
Fig.4
Insertion loss (
|S21|2) of the diode as a
function of frequency; typical values.
(1) IF = 100 mA.
(2) IF =10mA.
(3) IF = 1 mA.
(4) IF = 0.5 mA.
Diode inserted in series with a 50
stripline circuit
and biased via the analyzer Tee network.
Tamb =25 °C.
handbook, halfpage
0.5
3
0
30
20
10
1
f (GHz)
1.5
2
2.5
MCD776
S21
2
(dB)
Fig.5
Isolation (
|S21|2) of the diode as a function of
frequency; typical values.
Diode zero biased and inserted in series with a 50
stripline circuit.
Tamb =25 °C.
