December 1990
15
Philips Semiconductors
Product specication
8-channel analog multiplexer/demultiplexer
74HC/HCT4051
TEST CIRCUIT AND WAVEFORMS
Fig.19 Test circuit for measuring AC performance.
Conditions
TEST
SWITCH
Vis
tPZH
tPZL
tPHZ
tPLZ
others
VEE
VCC
VEE
VCC
open
VCC
VEE
VCC
VEE
pulse
FAMILY AMPLITUDE
VM
tr; tf
fmax;
PULSE WIDTH
OTHER
74HC
74HCT
VCC
3.0 V
50%
1.3 V
< 2ns
6ns
CL = load capacitance including jig and probe capacitance (see AC CHARACTERISTICS for values).
RT = termination resistance should be equal to the output impedance ZO of the pulse generator.
tr =tf = 6 ns; when measuring fmax, there is no constraint to tr, tf with 50% duty factor.
Fig.20 Input pulse definitions.
Conditions
TEST
SWITCH
Vis
tPZH
tPZL
tPHZ
tPLZ
others
VEE
VCC
VEE
VCC
open
VCC
VEE
VCC
VEE
pulse
FAMILY AMPLITUDE
VM
tr; tf
fmax;
PULSE WIDTH
OTHER
74HC
74HCT
VCC
3.0 V
50%
1.3 V
< 2ns
6ns
CL = load capacitance including jig and probe capacitance (see AC CHARACTERISTICS for values).
RT = termination resistance should be equal to the output impedance ZO of the pulse generator.
tr =tf = 6 ns; when measuring fmax, there is no constraint to tr, tf with 50% duty factor.
