TDA6101Q
Information as of 2000-08-22
TDA6101Q; Video output amplifier
The TDA6101Q is a video output amplifier with 9 MHz bandwidth. The device is contained in a single in-line 9-pin medium power
(DBS9MPF) package, using high-voltage DMOS technology, intended to drive the cathode of a colour CRT.
l
High bandwidth and high slew rate
l
No external heatsink required
l
Black-current measurement output for Automatic Black-current Stabilization (ABS)
l
Two cathode outputs; one for DC currents, and one for transient currents
l
A feedback output separated from the cathode outputs
l
Internal protection against positive appearing Cathode-Ray Tube (CRT) flashover discharges
l
ESD protection
l
Simple application with a variety of colour decoders
l
Differential input with a designed maximum common mode input capacitance of 3 pF, a maximum differential mode input
capacitance of 0.5 pF and a differential input voltage temperature drift of 20 mV/K
l
Defined switch-off behaviour.
