AD7841
REV. 0
C
P
–12–
OUTLINE DIMENSIONS
Dimensions shown in inches and (mm).
44-Lead MQFP (S-44)
0.548 (13.925)
0.546 (13.875)
0.398 (10.11)
0.390 (9.91)
(PINS DOWN)
1
33
34
44
11
12
23
22
0.033 (0.84)
0.029 (0.74)
0.016 (0.41)
0.012 (0.30)
0.083 (2.11)
0.077 (1.96)
0.040 (1.02)
0.032 (0.81)
0.040 (1.02)
0.032 (0.81)
SEATING
PLANE
0.096 (2.44)
MAX
0.037 (0.94)
0.025 (0.64)
8°
0.8°
GND
V
DD
8/10-BIT
DAC
GND
V
DD
8/10-BIT
DAC
LOGIC LEVEL
SHIFT
+5V
2
5V
SCLK
D IN
FSIN/CS
SCLK
D IN
FSIN/CS
0V TO +5V
0V TO
2
5V
V
REF
(+)AB
A0, A1, A2
V
OUT
A
V
OUT
A
V
OUT
B
V
OUT
B
V
REF
(
2
)AB
AD7841*
GND
DATA BUS
ADDR
DECODER
ADDR BUS
SDATA
SCLK
DATA BUS
CONTROLLER
*ADDITIONAL PINS OMITTED FOR CLARITY
Figure 22. Programmable Reference Generation for the AD7841
The AD8803 has an output voltage range of GND to V
DD
(0 V
to +5 V). To trim the V
REF
(+) input, the appropriate trim range
on the AD8803 DAC can be set using the V
REFL
and V
REFH
pins
allowing 8 bits of resolution between the two points. This will
allow the V
REF
(+) pin to be adjusted to remove gain errors.
To trim the V
REF
(–) voltage, some method of providing a trim
voltage in the required negative voltage range is required. Nei-
ther the AD7804 or the AD8803 can provide this range in nor-
mal operation as their output range is 0 V to +5 V. There are
two methods of producing this negative voltage. One method is
to provide a positive output voltage and then to level shift that
analog voltage to the required negative range. Alternatively
these DACs can be operated with supplies of 0 V and –5 V, with
the V
DD
pin connected to 0 V and the GND pin connected to
–5 V. Now these can be used to provide the negative reference
voltages for the V
REF
(–) inputs on the AD7841. However, the
digital signals driving the DACs need to be level-shifted from
the 0 V to +5 V range to the –5 V to 0 V range. Figure 22 shows
a typical application circuit to provide programmable reference
capabilities for the AD7841.
