REV. 0
AD8343
–23–
Table IV. Values of Matching Components Used for Receiver Characterization (Continued)
Component Designator
Value
Qty.
Part Number
f
IN
= 1900 MHz, f
OUT
= 170 MHz
T1B, T2B
T3B
R6B, R7B
Z1B, Z3B
Z4B
Z5B, Z7B
Z6B
L1B, L2B
Z2B, Z8B, L3B, L4B, R9B
—
Not Populate
d
1:1
4:1
10
6.8 nH
0.5 pF
100 nH
2.4 pF
56 nH
2
1
2
2
1
2
1
2
M/A-Com ETC1-1-13 Wideband Balun
1
Mini-Circuits TC4-1W Transformer
Panasonic ERJ6GEYJ100V (T and R Packaging)
Murata LQW1608A6N8C00
Murata MA180R5B
Murata LQW1608AR10G00
Murata MA182R4B
Panasonic ELJ-RE56NJF3
Table V. Values of Matching Components Used for Transmitter Characterization
Component Designator
Value
Qty.
Part Number
f
IN
= 150 MHz, f
OUT
= 900 MHz
T1B, T3B
T2B
R6B, R7B
Z1B, Z3B
Z2B
Z5B, Z7B
Z8B
L1B, L2B
L3B, L4B
Z4B, Z6B, R9B
—
Not Populated
1:1
1:1
5.1
8.2 nH
33 pF
8.2 nH
6.2 pF
56 nH
150 nH
2
1
2
2
1
2
1
2
2
M/A-Com ETC1-1-13 Wideband Balun
1
Mini-Circuits ADTL1-18-75
Panasonic ERJ6GEYJ510V (T and R Packaging)
Murata LQW1608A8N2C00
Murata GRM39C0G330J100V
Murata LQG11A8N2J00
Murata MA186R2C
Panasonic ELJ-RE56NJF3
Murata LQW1608AR15G00
f
IN
= 150 MHz, f
OUT
= 1900 MHz
T1B, T3B
T2B
R6B, R7B
Z1B, Z3B
Z2B
Z5B, Z7B
Z8B
L1B, L2B
L3B, L4B
Z4B, Z6B, R9B
—
Not Populated
1:1
1:1
5.1
8.2 nH
33 pF
1.8 nH
1.8 pF
56 nH
68 nH
2
1
2
2
1
2
1
2
2
M/A-Com ETC1-1-13 Wideband Balun
1
Mini-Circuits ADTL1-18-75
Panasonic ERJ6GEYJ510V (T and R Packaging)
Murata LQG11A8N2J00
Murata GRM39C0G330J100V
Murata LQG11A1N8S00
Murata MA181R8B
Panasonic ELJ-RE56NJF3
Murata LQW1608A68NG00
NOTES
1
The ECT1-1-13 wideband balun was chosen for ease in customer
’
s independent evaluation. These baluns are quite acceptable for use as T1 on the LO port, but may
not be acceptable for use as T2 on the high performance RF input. It has been found that board to board performance variations become unacceptable when
this balun is used at higher (> 500 MHz) frequencies. A narrow-band balun is suggested for this critical interface. Refer to the Device Interfaces and A Step-by-Step
Approach to Impedance Matching section of this document for more information.
