AD8344
OUTLINE DIMENSIONS
Rev. 0 | Page 20 of 20
1
0.50
BSC
0.60 MAX
PIN 1 INDICATOR
1.50 REF
0.50
0.40
0.30
0.25 MIN
0.45
2.75
BSC SQ
TOPVIEW
12° MAX
0.80 MAX
0.65 TYP
SEATING
PLANE
PIN 1
INDICATOR
1.00
0.85
0.80
0.30
0.23
0.18
0.05 MAX
0.02 NOM
0.20 REF
3.00
BSC SQ
1.65
1.50 SQ*
1.35
BVIEW
16
5
13
8
9
12
4
*COMPLIANTTO JEDEC STANDARDS MO-220-VEED-2
EXCEPT FOR EXPOSED PAD DIMENSION
Figure 51. 16-Lead Lead Frame Chip Scale Package [LFCSP]
3 mm × 3 mm Body (CP-16-3)
Dimensions in millimeters
ORDERING GUIDE
Models
AD8344ACPZ-REEL7
1
AD8344ACPZ-WP
1, 2
AD8344-EVAL
Temperature Range
40°C to +85°C
40°C to +85°C
Package Description
16-Lead Lead Frame Chip Scale Package (LFCSP)
16-Lead Lead Frame Chip Scale Package (LFCSP)
Evaluation Board
Package Option
CP-16-3
CP-16-3
Branding
JHA
JHA
1
Z = Pb-free part.
2
WP = Waffle pack.
2004 Analog Devices, Inc. All rights reserved. Trademarks and
regis-
tered trademarks are the property of their respective owners.
D04826–0–6/04(0)
