AD8370
Rev. 0 | Page 18 of 28
–100
–90
–80
–70
–60
–50
–40
H
0
96
32
64
0
32
64
96
128
GAIN CODE
0
HD2
HD2
LOW GAIN MODE
HIGH GAIN MODE
HD3
HD3
Figure 48. Harmonic Distortion of the Circuit in Figure 45
DC-COUPLED OPERATION
AD8370
I
I
V
P
V
V
O
O
O
O
V
L
C
D
I
I
6
7
8
2
3
5
1
11
10
9
15
14
16
13
12
4
SERIAL CONTROL
INTERFACE
1nF
1nF
0.1
μ
F
0.1
μ
F
–2.5V
–2.5V
0V
0V
+2.5V
R
L
SINGLE-
ENDED
GROUND
REFERENCED
SOURCE
R
S
R
T
0
Figure 49. DC Coupling the AD8370. Dual supplies are used to set the input
and output common-mode levels to 0 V.
AD8370
AD8138
I
I
V
P
V
V
O
O
O
O
V
L
C
D
I
I
6
7
8
2
3
5
1
11
10
9
15
14
16
13
12
4
SERIAL CONTROL
INTERFACE
1nF
1nF
0.1
μ
F
+5V
499
499
100
499
499
100
V
O
V
OCM
V
OCM
+5V
R
L
SINGLE-ENDED GROUND
REFERENCED SOURCE
R
S
R
T
R
T
2
0
Figure 50. DC Coupling the AD8370. The AD8138 is used as a unity gain level
shifting amplifier to lift the common-mode level of the source to midsupply.
The AD8370 is also a dc accurate variable gain amplifier. The
common-mode dc voltage present at the output pins is internally
set to midsupply using what is essentially a buffered resistive
divider network connected between the positive supply rail and
the common (ground) pins. The input pins are at a slightly
higher dc potential, typically 250 mV to 550 mV above the out-
put pins, depending on gain setting. In a typical single-supply
application, it is necessary to raise the common-mode reference
level of the source and load to roughly midsupply to maintain
symmetric swing and to avoid sinking or sourcing strong bias
currents from the input and output pins. It is possible to use
balanced dual supplies to allow ground referenced source and
load as indicated in Figure 49. By connecting the VOCM pin
and unused input to ground, the input and output common-
mode potentials are forced to virtual ground. This allows direct
coupling of ground referenced source and loads. The initial
differential input offset is typically only a few 100
μ
V. Over
temperature, the input offset could be as high as a few tens of
mVs. If precise dc accuracy is need over temperature and time, it
may be necessary to periodically measure the input offset and to
apply the necessary opposing offset to the unused differential
input, canceling the resulting output offset.
To address situations where dual supplies are not convenient, a
second option is presented in Figure 50. The AD8138 differential
amplifier is used to translate the common-mode level of the
driving source to midsupply, which allows dc accurate perform-
ance with a ground-referenced source without the need for dual
supplies. The bandwidth of the solution in Figure 50 is limited
by the gain-bandwidth product of the AD8138. The normalized
frequency response of both implementations is shown in Figure 51.
–10
–8
–6
–4
–2
0
2
4
6
8
10
N
1
10
100
1k
10k
100k
1M
10M
100M
1G
FREQUENCY (Hz)
0
AD8370 WITH
AD8138 SINGLE
+5V SUPPLY
AD8370
USING DUAL
±2.5V SUPPLY
Figure 51. Normalized Frequency Response of the Two Solutions in
Figure 49 and Figure 50
