AD8551/52/54
– 4 –
Rev. 0.2 05/06/97
ABSOLUTE MAXIMUM RATINGS
Supply Voltage.......................................................................+6V
Input Voltage...................................................GND to Vs + 0.3V
Differential Input Voltage
1
..................................................
±
5.0V
Output Short-Circuit Duration to Gnd.............................Indefinite
Storage Temperature Range
N, R Package...............................................-65°C to +150°C
Operating Temperature Range
AD8551/52/54A..........................................-40°C to +125°C
Junction Temperature Range
N, R Package...............................................-65°C to +150°C
Lead Temperature Range (Soldering, 10 sec).....................+300°C
Package Type
θ
JA
2
103
158
76
120
θ
JC
43
43
33
36
Units
°C/W
°C/W
°C/W
°C/W
8-Pin Plastic DIP (N)
8-Pin SOIC (R)
14-Pin Plastic DIP (N)
14-Pin SOIC(R)
NOTES
1 Differential input voltage is limited to ±5.0 volts or the supply voltage, whichever is less.
2
θ
JA is specified for the worst case conditions, i.e.,
θ
JA is specified for device in socket for
P-DIP packages;
θ
JAis specified for device soldered in circuit board for SOIC and TSSOP
packages.
ORDERING GUIDE
Temperature
Range
Package
Description
Package
Option
Model
AD8551AN
AD8551AR
AD8552AN
AD8552AR
AD8554AN
AD8554AR
-40°C to +125°C 8-Pin Plastic DIP
-40°C to +125°C 8-Pin SOIC
-40°C to +125°C 8-Pin Plastic DIP
-40°C to +125°C 8-Pin SOIC
-40°C to +125°C 14-Pin Plastic DIP
-40°C to +125°C 14-Pin SOIC
N-8
SO-8
N-8
SO-8
N-14
SO-14
APPLICATIONS
