AD8565/AD8566/AD8567
–
10
–
REV. A
Figure 5 shows the test circuit. Series capacitors and resistors
connected to the output of the op amp represent the load of the
LCD panel. The 300
and 3 k
feedback resistors are used to
improve settling time. This test circuit simulates the worst-case
scenario for a V
COM
. It drives a represented load that is connected
to a signal switched symmetrically around V
COM
. Figure 6 displays
a scope photo of the instantaneous output peak current capability
of the AD856x family.
INPUT 0V TO 8V
SQUARE WAVE WITH
15.6 s PULSEWIDTH
300
3k
10
10
10
10
10nF
10nF
10nF
10nF
MEASURE
CURRENT
4V
8V
10
–
20
Figure 5. V
COM
Test Circuit with Supply Voltage at 16 V
10
0%
100
90
TIME
–
2 s/DIV
CH 1 = 5V/DIV
1CH 2 =
Figure 6. Scope Photo of the V
COM
Instantaneous
Peak Current
