REV. 0
AD9845A
–13–
SHP
HD
3ns MIN
GAIN1
VD
GAIN0
GAIN2
GAIN3
3ns MIN
1. BOTH VD AND HD ARE INTERNALLY UPDATED AT SHP RISING EDGES.
2. VD = 0 AND HD = 0 SELECTS GAIN0.
3. VD = 0 AND HD = 1 SELECTS GAIN1.
4. VD = 1 AND HD = 0 SELECTS GAIN2.
5. VD = 1 AND HD = 1 SELECTS GAIN3.
GAIN0
PxGA
GAIN
NOTES:
Figure 20. PxGA Mode 7 (User-Specified) Detailed Timing
