AD9952
PIN FUNCTION DESCRIPTIONS
Table 3. 48-Lead TQFP/EP
Pin No.
Mnemonic
1
I/O UPDATE
Rev. 0 | Page 9 of 28
I/O
I
Description
The rising edge transfers the contents of the internal buffer memory to the I/O registers. This pin
must be set up and held around the SYNC_CLK output signal.
Digital Power Supply Pins (1.8 V).
Digital Power Ground Pins.
2, 34
3, 33, 42,
47, 48
4, 6, 13,
16, 18, 19,
25, 27, 29
5, 7, 14,
15, 17, 22,
26, 32
8
DVDD
DGND
I
I
AVDD
I
Analog Power Supply Pins (1.8 V).
AGND
I
Analog Power Ground Pins.
OSC/REFCLK
I
Complementary Reference Clock/Oscillator Input. When the REFCLK port is operated in single-
ended mode, REFCLK should be decoupled to AVDD with a 0.1 μF capacitor.
Reference Clock/Oscillator Input. See Clock Input section for details on the OSCILLATOR/REFCLK
operation.
Output of the Oscillator Section.
Control Pin for the Oscillator Section. When high, the oscillator section is enabled. When low, the
oscillator section is bypassed.
This pin provides the connection for the external zero compensation network of the REFCLK
multiplier’s PLL loop filter. The network consists of a 1 k resistor in series with a 0.1 μF capacitor
tied to AVDD.
Complementary DAC Output. Should be biased through a resistor to AVDD, not AGND.
DAC Output. Should be biased through a resistor to AVDD, not AGND.
DAC Biasline Decoupling Pin.
A resistor (3.92 k nominal) connected from AGND to DAC_R
SET
establishes the reference current
for the DAC.
Comparator Output.
Compator Input.
Compartor Complementary Input
Input Pin Used as an External Power-Down Control (see Table 8 for details).
Active High Hardware Reset Pin. Assertion of the RESET pin forces the AD9952 to the initial state,
as described in the I/O port register map.
Asynchronous Active High Reset of the Serial Port Controller. When high, the current I/O
operation is immediately terminated, enabling a new I/O operation to commence once IOSYNC is
returned low. If unused, ground this pin; do not allow this pin to float.
When operating the I/O port as a 3-wire serial port, this pin serves as the serial data output. When
operated as a 2-wire serial port, this pin is unused and can be left unconnected.
This pin functions as an active low chip select that allows multiple devices to share the I/O bus.
This pin functions as the serial data clock for I/O operations.
When operating the I/O port as a 3-wire serial port, this pin serves as the serial data input only.
When operated as a 2-wire serial port, this pin is the bidirectional serial data pin.
Digital Power Supply (for I/O Cells Only, 3.3 V).
Input Signal Used to Synchronize Multiple AD9952s. This input is connected to the SYNC_CLK
output of a master AD9952.
Clock Output Pin that Serves as a Synchronizer for External Hardware.
Input Pin Used to Control the Direction of the Shaped On-Off Keying Function when
Programmed for Operation. OSK is synchronous to the SYNC_CLK pin. When OSK is not
programmed, this pin should be tied to DGND.
The exposed paddle on the bottom of the package is a ground connection for the DAC and must
be attached to AGND in any board layout.
9
OSC/REFCLK
I
10
11
CRYSTAL OUT
CLKMODESELECT
O
I
12
LOOP_FILTER
I
20
21
23
24
IOUT
IOUT
DACBP
DAC_R
SET
O
O
I
I
28
30
31
35
36
COMP_OUT
COMP_IN
COMP_IN
PWRDWNCTL
RESET
O
I
I
I
I
37
IOSYNC
I
38
SDO
O
39
40
41
CS
SCLK
SDIO
I
I
I/O
43
44
DVDD_I/O
SYNC_IN
I
I
45
46
SYNC_CLK
OSK
O
I
<49>
AGND
I
