參數資料
型號: ADV7192
廠商: Analog Devices, Inc.
英文描述: Video Encoder with Six 10-Bit DACs, 54 MHz Oversampling and Progressive Scan Inputs
中文描述: 視頻編碼器與六10位DAC,54兆赫采樣和逐行掃描輸入
文件頁數: 51/69頁
文件大小: 664K
代理商: ADV7192
ADV7192
–51–
REV. 0
APPENDIX 6
OPTIONAL OUTPUT FILTER
If an output
fi
lter is required for the CVBS, Y, UV, Chroma and
RGB outputs of the ADV7192, the following
fi
lter in Figure 101
can be used in 2
×
Oversampling Mode. In 4
×
Oversampling
Mode the
fi
lter in Figure 103 is recommended. The plot of the
fi
lter characteristics are shown in Figures 102 and 104. An output
0.82 H
470pF
2.5 H
FILTER I/P
FILTER O/P
Figure 101. Output Filter for 2
×
Oversampling Mode
50
100k
–100
–50
0
100M
1.0G
–150
A
FREQUENCY – Hz
1.0M
10M
Figure 102. Output Filter Plot for 2
×
Oversampling Filter
fi
lter is not required if the outputs of the ADV7192 are connected
to most analog monitors or TVs, however, if the output signals
are applied to a system where sampling is used, (e.g., Digital
TVs) then a
fi
lter is required to prevent aliasing.
FILTER I/P
FILTER O/P
470pF
2.2 H
Figure 103. Output Filter for 4
×
Oversampling Mode
20
100k
–80
–40
–20
100M
1.0G
–100
A
FREQUENCY – Hz
1.0M
10M
0
–60
Figure 104. Output Filter Plot for 4
×
Oversampling Filter
27.0
40.5
54.0
13.5
6.75
FREQUENCY – MHz
2 FILTER
REQUIREMENTS
4 FILTER
REQUIREMENTS
0
–30
d
Figure 105. Output Filter Requirements in 4
×
Oversampling Mode
