Advanced Power
P-CHANNEL ENHANCEMENT MODE
Electronics Corp.
POWER MOSFET
▼ Lower On-resistance
BVDSS
-200V
▼ Simple Drive Requirement
RDS(ON)
680mΩ
▼ Fast Switching Characteristic
ID
-8A
▼ RoHS Compliant & Halogen-Free
Description
Absolute Maximum Ratings
Symbol
Units
VDS
V
VGS
V
ID@TC=25℃
A
ID@TC=100℃
A
IDM
A
PD@TC=25℃
W
W/℃
TSTG
℃
TJ
℃
Symbol
Value
Units
Rthj-c
Maximum Thermal Resistance, Junction-case
1.3
℃/W
Rthj-a
62.5
℃/W
Rthj-a
Maximum Thermal Resistance, Junction-ambient
110
℃/W
Data and specifications subject to change without notice
96
-55 to 150
Parameter
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current, VGS @ 10V
Total Power Dissipation
Operating Junction Temperature Range
Storage Temperature Range
-55 to 150
Linear Derating Factor
Continuous Drain Current, VGS @ 10V
-5
Pulsed Drain Current
1
30
+20
-8
0.77
Halogen-Free Product
AP9120GH/J-HF
Rating
-200
Maximum Thermal Resistance, Junction-ambient (PCB mount)
3
201005242
1
Thermal Data
Parameter
G
D
S
G
D
S
TO-252(H)
G
D
S
TO-251(J)
The TO-252 package is widely preferred for all commercial-industrial
surface mount applications and suited for low voltage applications
such as DC/DC converters. The through-hole version (AP9120GJ) is
available for low-profile applications.
