- 您現在的位置：買賣IC網 > PDF目錄48366 > AP9406MP (ADVANCED POWER ELECTRONICS CORP) 30 V, 0.018 ohm, N-CHANNEL, Si, POWER, MOSFET PDF資料下載
參數資料
| 型號： | AP9406MP |
| 廠商： | ADVANCED POWER ELECTRONICS CORP |
| 元件分類： | JFETs |
| 英文描述： | 30 V, 0.018 ohm, N-CHANNEL, Si, POWER, MOSFET |
| 封裝： | SOP-8 |
| 文件頁數： | 2/4頁 |
| 文件大小： | 69K |
| 代理商： | AP9406MP |
Electrical Characteristics@Tj=25
oC(unless otherwise specified)
Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Units
BVDSS
Drain-Source Breakdown Voltage
VGS=0V, ID=250uA
30
-
V
ΔBV
DSS/ΔTj
Breakdown Voltage Temperature Coefficient
Reference to 25℃, ID=1mA
-
0.02
-
V/℃
RDS(ON)
Static Drain-Source On-Resistance
2
VGS=10V, ID=9A
-
18
mΩ
VGS=4.5V, ID=7A
-
25
mΩ
VGS(th)
Gate Threshold Voltage
VDS=VGS, ID=250uA
1
-
3
V
gfs
Forward Transconductance
VDS=10V, ID=9A
-
15
-
S
IDSS
Drain-Source Leakage Current (Tj=25
oC)
VDS=30V, VGS=0V
-
1
uA
Drain-Source Leakage Current (Tj=70
oC)
VDS=24V, VGS=0V
-
25
uA
IGSS
Gate-Source Leakage
VGS=±20V
-
nA
Qg
Total Gate Charge
2
ID=9A
-
8
13
nC
Qgs
Gate-Source Charge
VDS=24V
-
2
-
nC
Qgd
Gate-Drain ("Miller") Charge
VGS=4.5V
-
4
-
nC
td(on)
Turn-on Delay Time
2
VDS=15V
-
7
-
ns
tr
Rise Time
ID=1A
-
6
-
ns
td(off)
Turn-off Delay Time
RG=3.3Ω,VGS=10V
-
19
-
ns
tf
Fall Time
RD=15Ω
-7
-
ns
Ciss
Input Capacitance
VGS=0V
-
620
1530
pF
Coss
Output Capacitance
VDS=25V
-
230
-
pF
Crss
Reverse Transfer Capacitance
f=1.0MHz
-
90
-
pF
Rg
Gate Resistance
f=1.0MHz
-
3.2
-
Ω
Source-Drain Diode
Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Units
VSD
Forward On Voltage
2
IS=2.5A, VGS=0V
-
1.2
V
t
rr
Reverse Recovery Time
2
IS=9A, VGS=0V,
-
24
-
ns
Qrr
Reverse Recovery Charge
dI/dt=100A/s
-
16
-
nC
Notes:
1.Pulse width limited by Max. junction temperature.
2.Pulse width <300us , duty cycle <2%.
3.Surface mounted on 1 in
2 copper pad of FR4 board, t <10sec ; 115 ℃/W when mounted on Min. copper pad.
AP9406MP
±100
