AVPro
5002C
Dual SCART A/V Switch
11
SCART Switching Table
INPUT PINS
Aux_R: Red input from Aux port
Enc_R: Red input from Enc port
Enc_B: Optional chroma input from Enc port
Enc_C: Chroma input from Enc port
Aux_G: Green input from Aux port
Enc_G: Green input from Enc port
Aux_B: Blue input from AUX SCART
Enc_B: Blue input from Enc port
ABLANK: Blanking input from Aux port
EBLANK: Blanking input from Enc port
Aux_YC: Composite input from Aux port
Enc_YC: Composite input from Enc port
Enc_Y: Luma input from Enc port
Enc_G: Optional luma input from Enc port
Aux_YC: Composite input from Aux port
Enc_YC: Composite input from Enc port
Enc_B: Optional composite input from Enc port
Aux_Cin/Aux_YC: sum of chroma and luma
Enc_C: Chroma input from Enc port
Enc_R: Optional chroma input from Enc port
Enc_B: Optional chroma input from Enc port
Enc2_C: Encoder 2 chroma input
Enc_YC: Composite input from Enc port
Enc_B: Optional composite input from Enc port
Enc_G: Optional luma input from Enc port
Enc_Y: Luma input from Enc port
TV_YCin: Composite input from TV SCART
Enc2_Y: Encoder 2 luma input
Aux_Lin: Left audio input from Aux port
Lin: Left audio input from audio DAC
TV_Lin: Left audio input from TV SCART
Aux_Lin: Left audio input from Aux port
Lin: Left audio input from audio DAC
Lin: Left audio input from audio DAC
TV_Lin: Left input from TV SCART
Aux_Rin: Right audio input from Aux port
Rin: Right audio input from audio DAC
TV_Rin: Right audio input from TV SCART
Aux_Rin: Right audio input from Aux port
Rin: Right audio input from audio DAC
Rin: Right audio input from audio DAC
TV_Rin: Right input from TV SCART
OUTPUT PIN
TV_R: Red video output to TV or SVHS chroma output to TV port
TV_G: Green video output to TV port
TV_B: Blue video output to TV port
BLANK: TV blanking output for RGB
(also can have internal 0V or 4V produced at this pin)
TV_YCout: Composite video, RGB sync, or Luma output to TV port
Mod_YC: Follows TV_YCout output. Composite (or luma sum
with chroma) output to RF modulator
Aux_Cout: Chroma output to auxiliary port
Aux_YCout: Composite video output to auxiliary port
Lout: Left audio output to RCA jack
TV_Lout: Left audio output to TV port
Aux_Lout: Left audio output to auxiliary port
Rout: Right audio output to RCA jack
TV_Rout: Right audio output to TV port
Aux_Rout: Right audio output to auxiliary port
