COMPACT BENCH–TOP TYPE
REGULATED DC POWER SUPPLY
C4720
The C4720 is a bench –top type multipurpose power supply
incorporating a high voltage power supply that provides
maximum output of +1.5kV for a photomultiplier tube and
constant voltage power supplies that provide 5V and 15V
for peripheral devices such as Hamamatsu photon counting
units. The four digit digital voltmeter on the front panel shows
the output value of high voltage with high accuracy.
lnformation furnished by HAMAMATSU is believed to be reliabIe. However, no responsibility is assumed for possibIe inaccuracies or ommissions. Specifications are
subject to change without notice. No patent right are granted to any of the circuits described herein.
1993 Hamamatsu Photonics K.K.
Subject to local technical requirements and regulations, availability of products included in this promotional material may vary. Please consult with our sales office.
Compact Bench-top Type Multipurpose Power Supply
Simultaneous Outputs of 5V, 15V and High Voltage
SPECIFICATIONS
FEATURES
Compact bench-top type
Simultaneous outputs of 5V, 15V and high
voltage (+200 to +1500V)
High stability
Parameter
High Voltage Power Supply Section
15V Power Supply Section
5V Power Supply Section
Output Voltage
+200 to +1500Vdc (variable)
(5.00 0.25) Vdc (fixed)
(15.00 0.75) Vdc (fixed)
Maximum Output Current
1mA
500mA
200mA
Input Regulation
a
0.001% Max.
0.1% Max.
0.1% Max.
Load Regulation
b
0.005% Max.
1% Max.
0.5% Max.
Ripple/noise
c
0.005%p-p Max.
8mVp-p Max.
Input Line Voltage
100/115/220Vac 10% (To be selected on order)
Dimensions
f
255(W) 54(H) 230(D)mm
Weight
Approx. 2.8kg
Input Line Voltage Frequency
50/60Hz
Power Consumption
c
Operating Temperature/
Humidity Range
e
Characteristics Guaranteed
Temperature/Humidity Range
e
Storage Temperature/
Humidity Range
e
Approx. 50VA Max.
0 to +40 , 90%RH Max.
8mVp-p Max.
Drift
d
0.03%/h Max.
0.05%/h Max.
0.05%/h Max.
Temperature Coefficient
0.03%/ Max.
0.03%/ Max.
Two 4-pin receptacles
(HIROSE SR30–10R–4S)
0.03%/ Max.
One 4-pin receptacle
(MIYAMA MC–032)
Output Receptacle
One MHV receptacle
High Voltage Output Monitor
High Voltage Output
Monitoring Accuracy
4–digit display
a : For 10% change in input voltage
b : For 0 to 100% change in load
c : At the maximum output
+5 to +35 , 85%RH Max.
–20 to +50 , 95%RH Max.
0.5% Max.
d : After 30-minutes warm-up
e : Without moisture condensation
f : Excluding projecting parts
