Information furnished by HAMAMATSU is believed to be reliable. However, no responsibility is assumed for possible inaccuracies or omissions.
Specifications are subject to change without notice. No patent rights are granted to any of the circuits described herein.
c
1998 Hamamatsu Photonics K.K.
Subject to local technical requirements and regulations, availability of products included in this promotional material may vary. Please consult with our sales office.
HIGH VOLTAGE POWER SUPPLY
SOCKET ASSEMBLY
WITH TRANSIMPEDANCE AMPLIFIER
C6271
HIGH VOLTAGE POWER SUPPLY SECTION
TRANSIMPEDANCE AMPLIFIER SECTION
The C6271 is a high voltage power supply socket assembly for 28 mm (1-1/8 inch) diameter side-on photomultiplier
tubes(PMT), incorporating a regulated high voltage power supply, an active voltage divider, and a transimpedance amplifier. It
enables simple yet stable PMT operations by only supplying +15 Vdc and connecting to a potentiometer or a 0 to +5 V for
high voltage adjustments.
Fast High Voltage Programming Response
Low Power Consumption
Wide High Voltage Output Range
Low Cost
FEATURES
Parameter
Description / Value
Unit
–
Vdc
Applicable PMT
Input Voltage
Input Current at Maximum High Voltage
Operating Temperature
Storage Temperature
28 mm(1-1/8 inch) diameter side-on types
+15
±
1
60
0 to +50
-20 to +60
mA Max.
°
C
°
C
Parameter
Description / Value
0 to -1250
±
0.01
0.008
0 to +5 V or external 50 k
potentiometer
80
±
0.01
Unit
Vdc
% Typ.
% p-p Typ.
–
ms Typ.
%/
°
C Typ.
Output Voltage Range
Line Regulation Against
±
1 V Input Change
Ripple/Noise in High Voltage Output
High Voltage Control
High Voltage Programming Response
a
Temperature Coefficient of High Voltage Output
GENERAL
Parameter
Value
Unit
V/
μ
A
V Typ.
Current to Voltage Conversion Factor
0.3
Maximum Linear Signal Output Voltage
+13(Anode Current=43
μ
A)
DC to 10
Bandwidth
kHz
Signal Output Offset Voltage
-0.3 to +0.3
mV Typ.
Induced Ripple on Signal Output
2
mVp-p Typ.
k
Min.
Load Resistance
2
NOTE:
a
For 0 to 99 % high voltage change
