Features
l
High throughput due to transmission grating made of quartz
l
Highly accurate optical characteristics
l
G9406GC: No external power supply required
(Uses USB bus power) *
1
l
Low noise measurement (Cooled type)
l
Compact design for easy assembly
l
Wavelength conversion factor *
2
is recorded in internal
memory
Applications
l
Water content measurement
l
Optical communication component testing
l
Film thickness measurement
C9913GC (TG-cooled NIR-
I
), C9914GB (TG-cooled NIR-
II
)
l
Water content measurement
l
Component analysis in food, agriculture fields, etc.
l
Process control for chemical products
M O D U L E
Integrating optical system, image sensor and circuit
C9406GC, C9913GC, C9914GB
Mini-spectrometer TG series
Hamamatsu TG series mini-spectrometers are polychromators integrated with optical elements and an image sensor. Light to be measured is
guided into the entrance port of TG series through an optical fiber and the spectrum measured with the built-in image sensor is output from the
USB port to a PC for data acquisition. Non-cooled type and cooled type are provided. Non-cooled type is a palmtop-size unit and operates on
USB bus power. Cooled type allows accurate measurement with low noise by cooling the image sensor. Two models are available: C9913GC
(TG-cooled NIR-
I
) and C9914GB (TG-cooled NIR-
II
). The TG series comes with sample software, device driver and DLL that let you easily set
measurement conditions and acquire, save and graphically display the spectrum data.
C9406GC (TG-NIR)
*1: C9913GC, C9914GB: Each requires 5 V and 12 V
power supplies.
*2: A conversion factor for converting the image sensor
pixel number into a wavelength is recorded in the
module. A calculation factor for converting the A/D
converted count into the input light intensity is not pro-
vided.
1
CMOS linear
image sensor
Type No.
Type
Image sensor
Spectral response range (nm)
800
1000
1200
C9409MA
200
400
600
1400
1600
1800
2000
2200
OEM model
9
340 to 780
Spectral resolution
(nm)
Type No.
Type
Spectral resolution
(nm)
Image sensor
Spectral response range (nm)
800
1000
1200
C10082CA
C10082CAH
C10082MD
C10083CA
C10083CAH
C10083MD
C9404CA
C9404CAH
C9404MC
C9405CA
C9405MC
C9406GC
C9913GC
C9914GB
TM-UV/VIS-CCD
High sensitivity
TM-VIS/NIR-CCD
High sensitivity
TM-VIS/NIR-CCD
High resolution
TM-VIS/NIR-MOS
Wide dynamic range
TG-UV-CCD
High sensitivity
TG-UV-MOS
Wide dynamic range
TM-UV/VIS-CCD
High resolution
TM-UV/VIS-MOS
Wide dynamic range
TG-SWNIR-CCD
High sensitivity
TG-SWNIR-MOS
Wide dynamic range
TG-cooled NIR-
I
Low noise (cooled type)
TG-NIR
TG-UV-CCD
High resolution
TG-cooled NIR-
II
Low noise (cooled type)
T
T
T
6
6
(
λ
=320 to 900 nm)
(
λ
=320 to 900 nm)
(
λ
=
550
to
900 nm)
(
λ
=
550
to
1100 nm)
8
3
3
5
5
7
7
8
1*
1*
Back-thinned type
CCD image sensor
Back-thinned type
CCD image sensor
Back-thinned type
CCD image sensor
Back-thinned type
CCD image sensor
Back-thinned type
CCD image sensor
CMOS linear
image sensor
CMOS linear
image sensor
CMOS linear
image sensor
NMOS linear
image sensor
InGaAs
linear
image sensor
200
400
600
1400
1600
1800
2000
2200
* Typ.
1100 to 2200
900 to 1700
500 to 1100
320 to 1000
200 to 400
200 to 800
n
Mini-spectrometer line-up
Non-cooled type
C9407MA
340 to 780
CMOS linear
image sensor
9
RC-VIS-MOS
Spectrometer module
RC-VIS-MOS
Spectrometer head
R
s
R
s
