1
CA2810C
MOTOROLA RF DEVICE DATA
Motorola, Inc. 1994
The RF Line
. . . designed for amplifier applications in 50 ohm systems requiring wide
bandwidth, low noise and low distortion. This hybrid provides excellent gain
stability with temperature and linear amplification as a result of the push–pull
circuit design.
Specified Characteristics at VCC = 24 V, TC = 25
°
C:
Frequency Range — 10 to 450 MHz
Output Power — 1 W Typ @ 1 dB Compression, f = 200 MHz
Power Gain — 34 dB Typ @ f = 50 MHz
PEP — 400 mW Typ @ –32 dB IMD
Noise Figure — 5 dB Max @ f = 300 MHz
All Gold Metallization for Improved Reliability
MAXIMUM RATINGS
Rating
Symbol
Value
Unit
DC Supply Voltage
VCC
Pin
TC
Tstg
28
Vdc
RF Power Input
+5
dBm
Operating Case Temperature Range
–20 to +100
°
C
Storage Temperature Range
–40 to +100
°
C
ELECTRICAL CHARACTERISTICS
(TC = 25
°
C, VCC = 24 V, 50
system unless otherwise noted)
Characteristic
Symbol
Min
Typ
Max
Unit
Frequency Range
BW
10
—
450
MHz
Gain Flatness (f = 10–450 MHz)
FL
PG
NF
—
—
±
1.5
dB
Power Gain (f = 50 MHz)
33
34
35
dB
Noise Figure, Boradband (f = 300 MHz)
—
—
5
dB
Power Output — 1 dB Compression (f = 200 MHz)
Po1 dB
ITO
800
1000
—
mW
Third Order Intercept (See Figure 10, f1 = 300 MHz)
Input/Output VSWR (f = 10–450 MHz)
—
43
—
dBm
VSWR
—
—
2:1
—
Second Harmonic Distortion
(Po = 100 mW, f2H = 10–300 MHz)
dso
—
–55
–45
dB
Reverse Isolation (f = 10–450 MHz)
—
—
40
—
dB
Peak Envelope Power
(Two Tone Distortion Test — See Figure 10)
(f = 10–450 MHz @ –32 dB IMD)
PEP
—
400
—
mW
Supply Current
ICC
270
310
330
mA
Order this document
by CA2810C/D
SEMICONDUCTOR TECHNICAL DATA
34 dB
10–450 MHz
800 mWATT
WIDEBAND
LINEAR AMPLIFIER
CASE 714F–03, STYLE 1
[CA (POS. SUPPLY)]
