FAN8422G
3
Pin Definitions
Pin Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Pin Name
FG_INPUT
(
)
AGC
INDEX PULSE WIDTH
VOLTAGE REGULATOR
INDEX BURST
INDEX OUTPUT
CE
SIGNAL GROUND
SIGNAL GROUND
FG ZERO CROSS
FG OUTPUT
RPM SELECT
CHARGE PUMP OUTPUT
OSC INPUT
NC
PHASE COMPENSATION
V
CC
CURRENT DETECTION2
U INPUT (
)
U INPUT (+)
NC
W PHASE OUTPUT
SIGNAL GROUND
V PHASE OUTPUT
U PHASE OUTPUT
V INPUT (+)
V INPUT (
)
CURRENT DETECTION1
HALL BIAS
FG INPUT (+)
I/O
I
I
O
O
O
O
I
-
-
O
O
I
O
I
-
I
-
I
I
I
-
O
-
O
O
I
I
I
I
I
Pin Function Description
Negative Input Pin FG Signal Amp.
Automatic Gain Control Input Pin
Index Pulse Width Detection Pin
Voltage Generator Output Pin
Index Pulse Width Detection Pin
Index Pulse Output Pin
Chip Enable (Active Low)
Signal Ground
Signal Ground
FG Signal Zero Cross Detection Pin
FG Signal Output Pin
RPM Selection Pin (L: 300, H: 360rpm)
Charge Pump Output Pin
1MHz Oscillation Input Pin
No Connection
Phase Compensation Cap. Connection Pin
5V Power Supply Pin
Over Current Detection Pin
Negative Input Pin of U Phase Amp
Positive Input Pin of U Phase Amp
No Connection
W Phase Output Pin
Signal Ground
V Phase Output Pin
U Phase Output Pin
Positive Input Pin of V Phase Amp
Negative Input Pin of V Phase Amp
Over Current Detection Pin
Hall Sensor Bias Input Pin
Positive Input Pin of FG Signal Amp
