FAN8623; PRELIMINARY
20
The digital ASIC continuously provides HIGH or OPEN signal until the Back-EMF generated is large enough to produce the
FG signal for the self commutation. During a fixed time, if the Back-EMF generated is too small and the spindle motor is not
driven by the self commutation, the ASIC resets all signals sent and retries the spindle.
Notes:
1. CNTL1: Spindle motor control
2. CNTL2: commutation mode control
3. CNTL3; VCM control
4. “1”: Enable; “0”: disable;
Acceleration Mode
When the Back-EMF detected is large enough to determine motor position, the mode is changed from start-up to acceleration.
The ASIC sends the optimum commutation timing signal via MCLK according to the FG input.
By using the Back-EMF, the spindle is self-commuted at acceleration and running modes. During the motor drive, the spindle
motor is commuted at that point which is electrically 30
°
delayed after the FG_Edge.
Running Mode
The running mode is when the spindle motor speed arrives within
±
1% of the target speed. The commutation mode, commu-
tation delay time, MCLK delay time (Td) and masking time are changed at the running mode.
The spindle motor speed is controlled by PWM signal within
±
0.01%.
The soft commutation using the current slope of the motor may reduce audiable noise, EMI (Electromagnetic Interference) and
spark voltage which is generated on the motor coil at the commutation.
CNTL1
(1)
CNTL2
(2)
Commutation
Hard
Hard
Soft
CNTL3
(3)
SPM driver
1
0
0
Brake
0
0
1
VCM driver
1
0
0
Retract
0
0
1
High
Open (Floating)
Low
