FAN8729
14
6. Calculation of Gain & Torque Current
Toque limit circuit limits the current of spindle motor.
Driver amp circuit limits the current of spindle motor by comparing the voltage detected from R
CS
and the voltage output
from torque sense map.
Output current of the motor can be limited by adjusting the R
CS
value.
Maximum output current of motor is found as follows;
VMAX within IC is fixed at 350mV.
Gm of torque sense amp is set to 0.71.
ER
ECR
VM1
Driver
Convertor
Current / Voltage
VM1
Gm
+
-
Transistors
Power
Distributor
Commutation
+
+
-
+
-
Vin
R1
+
-
Vmax
Values
Absolute
Feedback loop
Negative
H2
H3
H1
current limiting
Max. output
U
V
W
Io
VM1
Rcs
CS1(Pin11)
Io
+
Vs
-
Output
Current sense
Rcs
mV
Rcs
V
mA
Io
350
max
]
[
=
=
