參數資料
| 型號： | FDD8880 |
| 廠商： | FAIRCHILD SEMICONDUCTOR CORP |
| 元件分類： | JFETs |
| 英文描述： | N-Channel PowerTrench MOSFET |
| 中文描述： | 35 A, 30 V, 0.015 ohm, N-CHANNEL, Si, POWER, MOSFET, TO-252AA |
| 封裝： | DPAK-3 |
| 文件頁數： | 1/11頁 |
| 文件大小： | 127K |
| 代理商： | FDD8880 |
2004 Fairchild Semiconductor Corporation
September 2004
FDD8880 Rev. B1
F
FDD8880
N-Channel PowerTrench
MOSFET
30V, 58A, 9m
General Description
This N-Channel MOSFET has been designed specifically to
improve the overall efficiency of DC/DC converters using
either synchronous or conventional switching PWM
controllers. It has been optimized for low gate charge, low
r
DS(ON)
and fast switching speed.
Applications
DC/DC converters
Features
r
DS(ON)
= 9m
, V
GS
= 10V, I
D
= 35A
r
DS(ON)
= 12m
, V
GS
= 4.5V, I
D
= 35A
High performance trench technology for extremely low
r
DS(ON)
Low gate charge
High power and current handling capability
MOSFET Maximum Ratings
T
C
= 25°C unless otherwise noted
Thermal Characteristics
Package Marking and Ordering Information
Symbol
V
DSS
V
GS
Parameter
Ratings
30
±
20
Units
V
V
Drain to Source Voltage
Gate to Source Voltage
Drain Current
Continuous (T
C
= 25
o
C, V
GS
= 10V) (Note 1)
Continuous (T
C
= 25
o
C, V
GS
= 4.5V) (Note 1)
Continuous (T
amb
= 25
o
C, V
GS
= 10V, with R
θ
JA
= 52
o
C/W)
Pulsed
Single Pulse Avalanche Energy (Note 2)
Power dissipation
Derate above 25
o
C
Operating and Storage Temperature
I
D
58
A
51
13
A
A
A
mJ
W
W/
o
C
o
C
Figure 4
53
55
0.37
-55 to 175
E
AS
P
D
T
J
, T
STG
R
θ
JC
R
θ
JA
R
θ
JA
Thermal Resistance Junction to Case TO-252
2.73
o
C/W
o
C/W
o
C/W
Thermal Resistance Junction to Ambient TO-252
Thermal Resistance Junction to Ambient TO-252, 1in
2
copper pad area
100
52
Device Marking
FDD8880
Device
FDD8880
Package
TO-252AA
Reel Size
13”
Tape Width
12mm
Quantity
2500 units
D
G
S
G
S
D
(TO-252)
D-PAK
