March 1999
FDV301N
Digital FET , N-Channel
General Description Features
Absolute Maximum Ratings
T
A
= 25
o
C unless other wise noted
Symbol
Parameter
FDV301N
Units
V
DSS
, V
CC
V
GSS
, V
I
I
D
, I
O
Drain-Source Voltage, Power Supply Voltage
25
V
Gate-Source Voltage, V
IN
Drain/Output Current
8
V
- Continuous
0.22
A
0.5
P
D
T
J
,T
STG
ESD
Maximum Power Dissipation
0.35
W
Operating and Storage Temperature Range
-55 to 150
°C
Electrostatic Discharge Rating MIL-STD-883D
Human Body Model (100pf / 1500 Ohm)
6.0
kV
THERMAL CHARACTERISTICS
R
θ
JA
Thermal Resistance, Junction-to-Ambient
357
°C/W
FDV301N Rev.F
25 V, 0.22 A continuous, 0.5 A Peak.
R
DS(ON)
= 5
@ V
GS
= 2.7 V
R
DS(ON)
= 4
@ V
GS
= 4.5 V.
Very low level gate drive requirements allowing direct
operation in 3V circuits. V
GS(th)
< 1.5V.
Gate-Source Zener for ESD ruggedness.
>6kV Human Body Model
Replace multiple NPN digital transistors with one DMOS
FET.
This N-Channel logic level enhancement mode field effect
transistor is produced using Fairchild's proprietary, high cell
density, DMOS technology. This very high density process is
especially tailored to minimize on-state resistance. This
device has been designed especially for low voltage
applications as a replacement for digital transistors. Since
bias resistors are not required, this one N-channel FET can
replace several different digital transistors, with different bias
resistor values.
Mark:301
SOT-23
SuperSOT
TM
-8
SOIC-16
SO-8
SOT-223
SuperSOT
TM
-6
D
G
S
D
S
G
IN
GND
Vcc
INVERTER APPLICATION
OUT
1999 Fairchild Semiconductor Corporation
