2001 Fairchild Semiconductor Corporation
June 2001
FMC6G15US60 Rev. A3
IGBT
F
FMC6G15US60
Compact & Complex Module
General Description
Fairchild’s Insulated Gate Bipolar Transistor (IGBT) power
modules provide low conduction and switching losses as
well as short circuit ruggedness. They are designed for
applications such as motor control, uninterrupted power
supplies (UPS) and general inverters where short circuit
ruggedness is a required feature.
Features
UL Certified No. E209204
Short circuit rated 10us @ T
C
= 100
°
C, V
GE
= 15V
High speed switching
Low saturation voltage : V
CE
(sat) = 2.2 V @ I
C
= 15A
High input impedance
Built in 3 phase rectifier circuit
Fast & soft anti-parallel FWD
Applications
AC & DC motor controls
General purpose inverters
Robotics
Servo controls
Internal Circuit Diagram
R
S
T
P
P1
GU
EU
GU
GV
EV
GV
U
GW
EW
V
GW
W
E
N
B
Package Code : 21PM-AA
Absolute Maximum Ratings
T
C
= 25
°
C unless otherwise noted
Notes :
(1) Repetitive rating : Pulse width limited by max. junction temperature
Symbol
V
CES
V
GES
I
C
I
CM (1)
I
F
I
FM
P
D
T
SC
V
RRM
I
O
Description
FMC7G15US60
600
± 20
15
30
15
30
45
10
1200
20
Units
V
V
A
A
A
A
W
us
V
A
Inverter
Collector-Emitter Voltage
Gate-Emitter Voltage
Collector Current
Pulsed Collector Current
Diode Continuous Forward Current
Diode Maximum Forward Current
Maximum Power Dissipation
Short Circuit Withstand Time
Repetitive Peak Reverse Voltage
Average Output Rectified Current
Surge Forward Current
@ 1Cycle at 60Hz, Peak value Non-Repetitive
1 Cycle Surge Current
Operating Junction Temperature
Storage Temperature Range
Isolation Voltage
Mounting part Screw
@ T
C
= 25
°
C
@ T
C
= 100
°
C
@ T
C
= 25
°
C
@ T
C
= 100
°
C
Converter
I
FSM
200
A
I
2
t
T
J
T
STG
V
ISO
164
A
2
s
°
C
°
C
V
N.m
Common
-40 to +150
-40 to +125
2500
1.25
@ AC 1minute
@ M4
Mounting Torque
