FMM5051VU
Ku band Power Amplifier MMIC
FEATURES
High Output Power: 31.5dBm(typ.)
High Linear Gain: 31.5dB(typ.)
Low Input VSWR
Broad Band: 13.75~14.5GHz
Impedance Matched Zin/Zout = 50
Small Hermetic Metal-Ceramic SMT Package(VU)
DESCRIPTION
The FMM5051VU is a MMIC amplifier that contains a three-stage
amplifier, internally matched, for standard communications in the
13.75 to 14.5GHz frequency range. This product is well suited for
VSAT applications as it offers high power, high gain, and low VSWR.
Edition 2.0
January 2005
1
ABSOLUTE MAXIMUM RATING
Item
Drain-Source Voltage
Gate-Source Voltage
Input Power
Storage Temperature
Symbol
V
DD
V
GG
P
in
T
stg
Unit
V
V
dBm
o
C
RECOMMENDED OPERATING CONDITION
Item
DC Input Voltage
DC Input Voltage
Operating Case Temperature
Symbol
V
DD
V
GG
T
c
Unit
V
V
o
C
ELECTRICAL CHARACTERISTICS (Case Temperature Tc=25
o
C)
Min.
30.8
30.0
Typ.
31.5
31.5
800
35.0
1.5
-9
-9
Max.
Output Power
Linear Gain
(Note 1)
Total Drain Current
Power Added Efficiency
Gain Flatness
(Note 1)
Input Return Loss
(Note 1)
Output Return Loss
(Note 1)
Note 1 : P
in
=-10dBm
P
out
G
L
I
ddt
η
add
G
RL
in
RL
out
-
-
dBm
dB
mA
%
dB
dB
dB
-
-
-
-
-
1000
-
2.0
-6
-6
ESD
Note : Based on EIAJ ED-4701 C-111A(C=100pF, R=1.5k
)
CASE STYLE : VU
Class 0
~ 199V
V
DD
=5V
V
GG
=0V
f
=13.75~14.50GHz
P
in
=+3dBm
Unit
Rating
+8
-3
+8
-55 to +125
-40 to +85
0
+
5
Condition
Item
Symbol
Condition
Limit
Eudyna’s stringent Quality Assurance Program assures the highest
reliability and consistent performance.
